Model NO.:
F2-TH
Delivery:

Product Features
·Dynamic dual-camera anti-counterfeiting, completely solve the deception of various photos on various carriers
·Dual infrared and RGB fill light at night; Infrared temperature measurement, optional mask recognition
·Support external access control card reader, ID card reader
·Support RS-485 serial port, Wiegand 26/34 output interface, support relay, door switch, door magnetic output content
·Support 29,000 people to store historical records locally
·Support public network and local area network deployment
·Support HTTP interface connection
·Support screen display content configuration
·Support identification distance configuration

Identification height 1. 2-2.2 m
Identification distance 0.5- 1.5m (temperature test distance)
Recognition technology: Near-infrared live detection, embedded visible light face recognition, adapt to most indoor and outdoor environments, can quickly recognize on the move
5 ° C Accurate temperature detection: 2-3 seconds per person-time temperature detection accuracy

Status display Name broadcast display, custom information broadcast display

Product Parameters:

Face Recognition Integrated terminal

Product Model

F2-TH

Size

8 inch, full viewing angle, 170 degree IPS LCD screen

Screen Resolution

800*1200

Camera

Type

RGB

Infrared

Resolution

2 million pixels

Aperture

F2.8

FocalLength

3.18mm

WhiteBalance

Automatic

WideDynamic

Support

VerticalWideAngle

HorizontalWideAngle

Basic specifications

OperatingSystem

Android7.1 or above

EquipmentPower

DC12V(±10%)3A

EquipmentPowerConsumption

15w MAX

RelativeHumidity

0%¨90%(In a non-condensing state

)

OperatingTemperature

-20 ~60(Wall-mounted design: the junction with the eight or six boxes is not waterproof, and a ceiling is required)

ProtectionCass

IP55

UseEnvironment

Indoor/Ourdoor

EquipmentSize

275.2mm*123.2mm*30.2mm

Hardware Configuration

IdentificationMethod

BrushFace

Mifare card (optional: external purchase module required)

Resident ID card (optional: external purchase module required)

Face recognition parameters

Face verification accuracy>99%

Face recognition distance0.5m-1.5m

Face ID card comparison time600MS

Local capacity20,000 sheets

Port

Micro USB 1pcs

RJ45Gigabit1pcs

Relay, WiegandInterface, RS-485,DoorSensor,DoorSwitch

Support

Infrared/WhiteFillLight,

BasicParameters

Indicator Light

Support authentication success, Green light prompt; Authentication failure, Red light prompt

WIFI

2.4G 802.11b/g/n

Bluetooth

Bluetooth4.0

4G LTE

Full Netcom (optional: custom purchase required)

TemperatureMeasurementModule

Operating Temperature

-20℃ ~ +85℃

Storage

Temperature

-40℃ ~ +85℃

Power Consumption

< 0.3w

Pixel

32*32 Real-time temperature output

Measurement Accuracy

I + 0.5

Measuring Distance

0.5 ~ 1.5m
